Atkinson GSCM-Mini-P (Push Start/Stop)

NOTE: There are several different types of auto-start modules  and which one you need is dependent on your generator make and model. If you have not done so, please contact us @ 740-234-3434 or upgrade@offgridps.com to make sure this module is compatible with yours.

The Generator Start Control Module-mini-P (GSCM-mini-P) is a non-programmable micro-processor based generator start controller that is designed to auto start and stop gas, duel fuel or tri-fuel generators.

The GSCM-mini-P supports three types of 3 or 4 wire push to start, multiple attempt generators including:

Champion model # 100573

Cummins/Onan model #’s P4500I, P9500DF

Westinghouse model #’s IGen4500, WGen4500I, WGen7500DF, WGen9500DF

Duramax model # XP1300EH Duel Fuel

It provides a 1-second start pulse to the generator micro-processor to start the engine. It then drops into run mode when an AC or pilot lamp voltage is detected.  The GSCM-mini-P is powered by 12 volts DC from the generator battery and can monitor the battery voltage and start the generator to charge its own battery.

The GSCM-mini-P is also available in a mini, mini diesel version or a programmable version.  See GSCM-mini, GSCM-mini-d or GSCM.

Dimensions:  W: 3.2” x  H: 1.2" x  D: .875"
