Tamarack Horizontal Pole Mount for (3) modules 38"-72" long, 1 pole

THREE MODULE POLE MOUNT UNI-PGRM/3P1 (for modules 38”- 72” long)

• Mount two solar modules with a total area of 75 sq-ft and a frame thickness between 1.18-inches and 2-inches*

• Suitable for wind speed up to 150 MPH and snow load up to 100 PSF snow load with a maximum post height of 6-feet above ground

• Tilt angle from 10° to 60°

• Ships via UPS - 2 Boxes

• Simple one-person installation and adjustment

Some wind speeds and snow loads require two vertical poles and/or Sch-80 horizontal/vertical pipe. If an additional vertical pole is required, order a 70-0300-PGM-B Pole Cap. Refer to spec sheet for additional evaluation.

*Vertical and Horizontal Pipe is not included

** Larger modules can be mounted with reduced wind and snow load
